CSA O86:19 CLT Building Design in RFEM 6 (USA)

Webinars provide the opportunity to gain expert knowledge and to ensure you’re getting the most out of your Dlubal programs.
CSA O86:19 CLT Building Design in RFEM 6
CSA O86:19 CLT Building Design in RFEM 6 (USA)
2024-05-21
2:00 PM - 3:00 PM EDT
English (US)
Free
EN-US | Flag Event
Webinar | CSA O86:19 CLT Building Design in RFEM 6
Free Webinar | CSA O86:19 CLT Building Design in RFEM 6 (USA)

This webinar will provide the design workflow for multistory CLT buildings acc. to the CSA O86:19 in RFEM 6.
Time Schedule
00:00
Introduction
03:18
Example 1: Timber floor model review
24:25
Loading and Load Combinations
32:55
Timber Design Add-on data input
39:45
Analysis and design results
45:08
Modal Analysis Add-on vibration analysis
47:55
Example 2: Multistory building model review
49:45
Building Model Add-on data input
56:52
Analysis and design results
1:02:21
Conclusion

Presentation Model to Download

Below, under Models to Download, you will find the model(s) used in the webinar. This will allow you to independently follow the webinar step by step with the provided model after the presentation is complete.

Location

Online
Links
Downloads
Presentation Slides to Webinar "CSA O86:19 CLT Building Design in RFEM 6" (PDF)
1.22 MB
