9 Special Features in RFEM 6 You Should Know

In this webinar, we show you 9 special features in RFEM 6 you should know.
Nine special features in RFEM 6 are highlighted emphasizing advanced analysis options and enhanced modeling capabilities.
9 Special Features in RFEM 6 You Should Know
2025-05-28
2:00 PM - 3:00 PM CEST
English
Add to Calendar Register
Free
EN-US | Flag Product Feature
RFEM 6 | FEA Software

Free Webinar

After the event, you can find the models presented in the webinar below, under Models to Download. This allows you to independently follow the webinar step by step.

Furthermore, each participant will receive a certificate with the name specified during the registration.

Time Schedule
-
Introduction
-
Intersections
-
Surface result adjustments
-
Surface contacts
-
Rigid links
-
Structure modifications
-
Nodal releases
-
Line releases
-
Surface releases
-
Blocks

Notes

During the presentation, you can ask individual questions.

A computer with internet access is required as well as a loudspeaker, headphones, headset or any other listening device. Alternatively, you can dial in using a phone line for audio connection.

Take advantage of this free webinar and sign up today! The number of participants is limited. After your registration is complete, you will receive a confirmation email, including the information on how to join the webinar.

Sonja von Bloh, M.Sc.

Product Engineering & Customer Support

Ms. von Bloh provides technical support for our customers and is responsible for the development of the SHAPE‑THIN program as well as steel and aluminum structures.

Dipl.-Ing. (FH) Andreas Hörold

Marketing & Public Relations

Mr. Hörold takes care of the Dlubal Software website, moderates the German and English webinars, and creates newsletters and marketing materials.

Location

Online
