The model includes a steel platform with supporting fasteners that are realized by deliberately using rigid frame joints. The optimized steel joints allow for direct force transmission, which increases the overall load-bearing capacity. Precise detailing ensures that manufacturing requirements are accurately taken into account and stable structures are guaranteed.
Model Used in
Overall
This page has 0 user ratings.
| 5 star | ||
| 4 star | ||
| 3 star | ||
| 2 star | ||
| 1 star |
Steel Platform with Steel Joints
| Number of Nodes | 26 |
| Number of Lines | 33 |
| Number of Members | 17 |
| Number of Surfaces | 4 |
| Number of Solids | 0 |
| Number of Load Cases | 4 |
| Number of Load Combinations | 21 |
| Number of Result Combinations | 0 |
| Total Weight | 2,008 t |
| Dimensions (Metric) | 6,000 x 6,000 x 4,900 m |
| Dimensions (Imperial) | 19.69 x 19.69 x 16.08 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
