Snow, wind, and passenger load-resistant summit station of 3S cable car.
  • Description
  • Reviews (0)

The summit station of the 3S cable car is a structure that has to withstand heavy snow and wind loads, in addition to the loads of the cables carrying the passenger cabins. This is a customer project with a special design to guarantee the safety and comfort of users. This type of station is essential for the efficient operation of mountain cable transport systems.

Overall
0 out of 5 stars
This page has 0 user ratings.
5 star
4 star
3 star
2 star
1 star
(0)
0 out of 5 stars
5 star 0
4 star 0
3 star 0
2 star 0
1 star 0

3S Cable Car – Mountain Station at 3,200 m Above Sea Level

No Download Possible Customer Project / View Only
Number of Nodes 675
Number of Lines 1168
Number of Members 680
Number of Surfaces 56
Number of Load Cases 10
Number of Load Combinations 1
Number of Result Combinations 21
Total Weight 4294.472 t
Dimensions (Metric) 62.961 x 40.861 x 20.263 m
Dimensions (Imperial) 206.56 x 134.06 x 66.48 feet
Program Version 5.33.01
