RSECTION 1 | Students | Introduction to Strength of Materials

As a student, learn how to work more efficiently with RFEM. In the training, we discuss the essential modeling functions and workflows using practical examples. Live Q&A with the instructor is possible during the course.
Online Training | English
RSECTION 1 | Students | Introduction to Strength of Materials
2025-05-07
4:00 PM - 5:00 PM CEST
English
Add to Calendar Register
Free
EN-US | Flag Product Feature
RFEM 6 | FEA Software

Free online basic training for students on the cross-section program RSECTION 1 and the structural FEA software RFEM 6 | Introduction to Strength of Materials

As a student, learn how to work more efficiently with RFEM. In the training, we discuss the essential modeling functions and workflows using practical examples. Live Q&A with the instructor is possible during the course.

Time Schedule
-
Introduction
-
Introduction to cross-section properties software RSECTION 1
-
Introductory example: thin-walled I-section
-
Thin-walled I-section according to the thin-walled analysis
-
Massive cross-section according to an FE analysis
-
Hybrid Cross-Section

Notes

The online training requires a fast and reliable internet connection.

After completing the training, you will receive a certificate. Also, the models presented in the training, the video recording and documents will be available for download on our website. This allows you to go through and understand the training step by step.

Dipl.-Ing. (FH) Richard Haase

Product Engineering & Customer Support

Mr. Haase is responsible for development in the area of reinforced concrete structures, and provides technical support to our customers.

Links
Downloads
Presentation Slides to Online Training "RFEM 6 | Students | Introduction to Strength of Materials" (PDF)
600.82 KB
Example 1 for Online Training "RSECTION 1 | Students | Introduction to Strength of Materials" (RSC)
553.83 KB
Example 2 for Online Training "RSECTION 1 | Students | Introduction to Strength of Materials" (RSC)
783.03 KB
Example 3 for Online Training "RSECTION 1 | Students | Introduction to Strength of Materials" (RSC)
1.51 MB
Example 4 for Online Training "RSECTION 1 | Students | Introduction to Strength of Materials" (RSC)
602.44 KB
Aluminum Section for Online Training "RSECTION 1 | Students | Introduction to Strength of Materials" (DXF)
110.11 KB
