RFEM for Students

With this online group training, learn the basic principles of the software. After completion, you will be able to model and analyze simple structures in RFEM.
Online Training | English
RFEM for Students
2020-07-22
1:00 PM - 4:00 PM EDT
English (US)
Free
EN-US | Flag
Online Training | RFEM for Students | RFEM Basics & Practical Modeling Examples
Free online basic training of the structural FEA software RFEM for students

As a student, learn how to work more efficiently with the RFEM software. The essential modeling functions and workflow will be discussed using practical examples including basic beam and surface structures. Live Q&A with the instructor is possible during the course.

The goal of this course is to become familiar with the program basics. After completion, students will have a basic understanding on how to model, analyze, and design basic member and surface structures.
Time Schedule
-
Introduction to the structural analysis software RFEM
-
Detailed workflow with beam design examples
-
Detailed workflow with surface design examples
-
Question and answer opportunities

Costs

FREE for students with valid college/university proof of enrollment certificate sent to training@dlubal.com

Notes

The online training requires a fast and reliable internet connection.

During the training, each participant can ask questions at any time using the chat option.

After the event, each participant will have access to the models, video recording, and training documents presented in the training on our website. The website link will be sent by email after the training. Participants can revisit the course details step by step with the provided training material.

After completing the training, each participant will receive a certificate.

Amy Heilig, PE

CEO – USA Subsidiary | Sales Engineer

Amy Heilig is the CEO of the USA Subsidiary and responsible for sales and continued program development for the North American market.

Alex Bacon, EIT

Support Engineer

Alex is responsible for customer training, technical support, and continued program development for the North American market.
