Solid with Layered FE Mesh
  • Description
  • Reviews (0)

The model shows the possibility of arranging a layered mesh in addition to a holistic FE mesh refinement in extended solids. In this process, the solid is subdivided into precise individual mesh layers by a defined division between two parallel surfaces, whereby FE elements are arranged in a targeted manner. The arrangement promotes improved element modeling, which is particularly suitable for geometries with small height dimensions. The visualization shows clearly defined mesh areas that highlight the layered structure and the effect of the FE elements.

Model Used in
Overall
0 out of 5 stars
This page has 0 user ratings.
5 star
4 star
3 star
2 star
1 star
(0)
0 out of 5 stars
5 star 0
4 star 0
3 star 0
2 star 0
1 star 0

Layered FE Mesh in Solids

Number of Nodes 8
Number of Lines 12
Number of Surfaces 6
Number of Solids 1
Total Weight 2.355 t
Dimensions (Metric) 1.000 x 2.000 x 0.150 m
Dimensions (Imperial) 3.28 x 6.56 x 0.49 feet
Program Version 5.25.01

You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
