The nested components of a telescopic boom of a construction machine, for example, transport their forces mechanically between the components. This model was used to show how to solve this specific force transmission in terms of modeling.
Model Used in
Telescopic Boom
| Number of Nodes | 4 |
| Number of Lines | 4 |
| Number of Members | 4 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.422 tons |
| Dimensions (Metric) | 6,000 x 0,000 x 0,000 m |
| Dimensions (Imperial) | 19.69 x 0 x 0 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
