For a beam that is only subjected to tension, the reinforcement is determined according to EN-1992-1-1. This model was used to show how the RFEM calculation software automatically processes data about the concrete reinforcement required according to the Eurocodes.
Model Used in
Statically Determinate Beam
| Number of Nodes | 2 |
| Number of Lines | 1 |
| Number of Members | 1 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 2 |
| Number of Load Combinations | 8 |
| Number of Result Combinations | 4 |
| Total Weight | 0.500 tons |
| Dimensions (Metric) | 5.000 x 0.000 x 0.000 m |
| Dimensions (Imperial) | 16.4 x 0 x 0 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
