Steel Dome
  • Description
  • Reviews (0)

The Kuchlbauer Tower in Abensberg, designed by Friedensreich Hundertwasser, is a 34.19 m high steel dome. This architectural work was designed during the artist's planning phase before he died in 2000. The structural design was carried out by the engineering office Uhrmacher GmbH. The tower is located on the grounds of the Kuchlbauer brewery in Lower Bavaria. You can find more information at Uhrmacher GmbH.

Model Used in
Overall
0 out of 5 stars
This page has 0 user ratings.
5 star
4 star
3 star
2 star
1 star
(0)
0 out of 5 stars
5 star 0
4 star 0
3 star 0
2 star 0
1 star 0

Steel Dome of Kuchlbauer Tower

No Download Possible Customer Project / View Only
Number of Nodes 348
Number of Members 508
Number of Load Cases 4
Number of Load Combinations 7
Number of Result Combinations 1
Total Weight 4.174 t
Dimensions (Metric) 9.700 x 9.700 x 5.480 m
Dimensions (Imperial) 31.82 x 31.82 x 17.98 feet
Program Version 7.04.09
