Download the model of a timber hall here, and open it with the FEA software RFEM.
This model is used in the following two free webinars:
- "Member and Surface Structures Made of Timber | Part 1: Modeling, Load Input, Combinatorics" presented on May 4, 2021 (in English; on April 20, 2021, in German)
- "Member and Surface Structures Made of Timber | Part 2: Design" presented on May 11, 2021 (in English; on April 27, 2021, in German)
Model Used in
Timber Hall
| Number of Nodes | 124 |
| Number of Lines | 143 |
| Number of Members | 130 |
| Number of Surfaces | 1 |
| Number of Load Cases | 12 |
| Number of Load Combinations | 172 |
| Number of Result Combinations | 4 |
| Total Weight | 20.321 tons |
| Dimensions (Metric) | 20.122 x 18.122 x 6.061 m |
| Dimensions (Imperial) | 66.02 x 59.46 x 19.89 feet |
| Program Version | 5.26.00 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
Length: 01:06:40 min
Length: 01:04:39 min
Length: 01:08:02 min
Length: 00:01:22 min
Length: 00:00:56 min
Length: 00:55:27 min
Length: 01:10:03 min
