Optimization in RFEM 6 Using Blocks

In this webinar, we will show you how to optimize structures in RFEM 6 using blocks.
Optimization in RFEM 6 Using Blocks
Optimization in RFEM 6 Using Blocks
2025-01-23
2:00 PM – 3:00 PM CET
English
Free
Webinar announcement for optimizing block‐based modeling in engineering software.
EN-US | Flag General
Webinar | Optimization in RFEM 6 Using Blocks
Time Schedule
00:00
Introduction
02:35
New features in the Optimization & Cost / CO₂ Emission Estimation add-on
38:25
Optimizing the structural system of a steel hall as a block

Below, under Models to Download, you will find the model(s) used in the webinar. This will allow you to independently follow the webinar step by step with the provided model(s) after the presentation is complete.

Dipl.-Ing. Florian Hiddemann

Product Manager

Mr. Hiddemann is responsible for the development and quality assurance of Dlubal programs.

Dipl.-Ing. (FH) Andreas Hörold

Marketing & Public Relations

Mr. Hörold takes care of the Dlubal Software website, moderates the German and English webinars, and creates newsletters and marketing materials.

Location

Online
Links
Downloads
Presentation Slides to Webinar "Optimization in RFEM 6 Using Blocks" (PDF)
1.36 MB
