Response Spectrum Analysis - Optimizations to Achieve the Effective Modal Mass

In this webinar, we will show you optimizations in response spectrum analysis to achieve the effective modal mass.
Illustration showing optimization methods in response spectrum analysis for effectively achieving modal masses in structural analysis.
Response Spectrum Analysis - Optimizations to Achieve the Effective Modal Mass
2025-06-18
2:00 PM - 3:00 PM CEST
English
Add to Calendar Register
Free
EN-US | Flag Product Feature
RFEM 6 | FEA Software

Free Webinar

After the event, you can find the models presented in the webinar below, under Models to Download. This allows you to independently follow the webinar step by step.

Furthermore, each participant will receive a certificate with the name specified during the registration.

Time Schedule
-
Introduction
-
Overview and features of the dynamic add-ons in RFEM 6 and RSTAB 9
-
Response spectrum analysis: description of the desired analysis
-
Description of the models used
-
Modal analysis: natural vibrations of the structure, effective modal masses
-
Response spectrum analysis
-
Selection of the response spectrum for design
-
Combinatorics settings
-
Evaluation and interpretation of the results
-
Concluding remarks

Notes

During the presentation, you can ask individual questions.

A computer with internet access is required as well as a loudspeaker, headphones, headset or any other listening device. Alternatively, you can dial in using a phone line for audio connection.

Take advantage of this free webinar and sign up today! The number of participants is limited. After your registration is complete, you will receive a confirmation email, including the information on how to join the webinar.

Thomas Eichner, MSc.

Product Engineering & Customer Support

Mr. Eichner is responsible for the development of products for dynamic analysis and provides technical support for our customers.

Dipl.-Ing. (FH) Andreas Hörold

Marketing & Public Relations

Mr. Hörold takes care of the Dlubal Software website, moderates the German and English webinars, and creates newsletters and marketing materials.
