Masonry garage.
Garage
Number of Nodes | 41 |
Number of Lines | 49 |
Number of Members | 12 |
Number of Surfaces | 6 |
Number of Solids | 0 |
Number of Load Cases | 2 |
Number of Load Combinations | 4 |
Number of Result Combinations | 0 |
Total Weight | 113.211 tons |
Dimensions | 31.17 x 11.48 x 22.97 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
The material model Orthotropic Masonry 2D is an elastoplastic model that additionally allows softening of the material, which can be different in the local x- and y-directions of a surface. The material model is suitable for (unreinforced) masonry walls with in-plane loads.
