The model presented in the video shows how to model contacts using surface releases and special meshing options for solid elements, as well as how to connect members to surfaces and solid elements. The plastic analysis using RF-MAT NL visualizes stress redistributions in the structural system. It provides a practical example of the use of nonlinear material models in steel structures. The approaches presented allow for precise simulations for challenging connection problems. ModelGroup0002 also illustrates the possible applications of cross-module calculations.
