RFEM for Students | Part 1

With this online group training, you will learn the basics and structure of the software, so that you will then be able to model and calculate simple structural structures.
Online Training | English
RFEM for Students | Part 1
2020-06-09
9:30 AM - 12:00 PM CEST
English
Free
EN-US | Flag Product Feature
RFEM 6 | FEA Software
Free online basic training of the structural FEA software RFEM for students

Learn as student how to work more efficiently with the RFEM software. The essential modeling functions and workflow will be discussed using practical examples. Live Q&A with the instructor is possible during the course.

The main focus of the first part of this online training is getting to know the program. The examples are practical and link the theoretical knowledge from your studies.

Topics such as the comparison of bar and surface elements as well as the treatment of an Euler case are dealt with in detail in this event.
Time Schedule
-
Basic principle of FEM
Explanation and definition of the finite element method
Schematic sequence of an FEM calculation
-
Introduction to the RFEM 5 program Structure and basic work with RFEM 5 How a project works Explanation of the user interface
-
Introductory example: continuous plate Comparison of beam element and surface element
Modeling two-field beams
Modeling rectangular plate
-
Stability analysis: Euler case 1 Modeling a cantilever
Calculation of critical buckling load
Calculation of buckling length
-
Clamped frame Modeling and stability analysis
Difference between 2D and 3D calculation

Costs

Free of charge for students provided that a current valid certificate is sent to training@dlubal.com

Notes

The online training requires a fast and reliable internet connection.

During the training, each participant can ask questions at any time using the chat option.

After the event, each participant will find the models, video recordings and training documents presented in the training on our website. The website link will be sent by email after the training.
This allows the participant to go through and understand the training step by step by means of the models.

After completing the training, each participant receives a certificate.

Dipl.-Ing. Praxitelis Dimitriadis

Marketing Manager

Mr. Dimitriadis is responsible for creating targeted social media content and video marketing. He is also responsible for the Online Learning Academy.
