Composite Timber Beams
  • Description
  • Reviews (0)

The model presents the consideration of the flexibility of connections in composite timber cross-sections by entering the reduction factor gamma. The gamma method, as defined in DIN 1052:2008 (8.6.2) and EN 1995-1-1 (Annex B), allows for a realistic simulation of the connection layers. The implementation is exemplified in RFEM 5 and RSTAB 8 and thus illustrates the practical application of the method. The combination of materials and the technical procedure provide a detailed insight into the functioning of composite beams.

Model Used in
Overall
0 out of 5 stars
This page has 0 user ratings.
5 star
4 star
3 star
2 star
1 star
(0)
0 out of 5 stars
5 star 0
4 star 0
3 star 0
2 star 0
1 star 0

Composite Timber Beam Gamma Method

Number of Nodes 6
Number of Members 3
Number of Load Cases 1
Total Weight 0,293 t
Dimensions (Metric) 5.467 x 0.467 x 4.467 m
Dimensions (Imperial) 17.94 x 1.53 x 14.66 feet
Program Version 8.25.01

You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
