Download the model of a rigid connection here, and open it with the structural FEA software RFEM.
This model is shown in the free webinar "Analysis of Steel Joints Using Finite Element Model in RFEM 6" on February 24, 2022 (in English; on February 22, 2022 in German).
Model Used in
Rigid Steel Connection | 2
| Number of Nodes | 62 |
| Number of Lines | 91 |
| Number of Members | 89 |
| Number of Surfaces | 6 |
| Number of Solids | 0 |
| Number of Load Cases | 5 |
| Number of Load Combinations | 10 |
| Number of Result Combinations | 0 |
| Total Weight | 7.096 tons |
| Dimensions (Metric) | 13.000 x 6.001 x 15.000 m |
| Dimensions (Imperial) | 42.65 x 19.69 x 49.21 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
