Rigid Beam Connection with Contact Solid
  • Description
  • Reviews (0)

This model of a rigid beam connection with a contact solid can be opened and analyzed using the finite element analysis software RFEM. It is presented in the free webinar “The Most Common User Errors in RFEM and RSTAB,” which was held on February 4, 2021 (in English) and on January 28, 2021 (in German). The model presented in the webinar vividly demonstrates the use of solids and contacts in the context of structural engineering.

Model Used in
Overall
0 out of 5 stars
This page has 0 user ratings.
5 star
4 star
3 star
2 star
1 star
(0)
0 out of 5 stars
5 star 0
4 star 0
3 star 0
2 star 0
1 star 0

Rigid Beam Connection with Contact Solid

Number of Nodes 82
Number of Lines 83
Number of Members 8
Number of Surfaces 30
Number of Solids 1
Number of Load Cases 1
Total Weight 0,078 t
Dimensions (Metric) 0.117 x 4.142 x 0.220 m
Dimensions (Imperial) 0.38 x 13.59 x 0.72 feet
Program Version 5.24.02

You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
