In this model, the stress/strain results of two plate connections are compared. The model is designed once as a shear hole bearing connection and once as a welded connection.
The analysis is performed using the Nonlinear Material Behavior and Stress-Strain Analysis add-ons.
Comparison of Plate Connection
| Number of Nodes | 41 |
| Number of Lines | 35 |
| Number of Members | 0 |
| Number of Surfaces | 9 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 1 |
| Number of Result Combinations | 0 |
| Total Weight | 0.009 tons |
| Dimensions (Metric) | 0,290 x 0,020 x 0,325 m |
| Dimensions (Imperial) | 0.95 x 0.07 x 1.07 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
