High-Rise Building
  • Description
  • Reviews (0)
Download the model of a high-rise building here, and open it with the finite element program RFEM.

This model is used in the free webinar "Calculation of Multilayer Surfaces and Using Building Models in RFEM 6" on September 28, 2022 (in English; on September 20, 2022, in German).

Model Used in
Overall
0 out of 5 stars
This page has 0 user ratings.
5 star
4 star
3 star
2 star
1 star
(0)
0 out of 5 stars
5 star 0
4 star 0
3 star 0
2 star 0
1 star 0

High-Rise Building

Number of Nodes 1581
Number of Lines 2329
Number of Members 1026
Number of Surfaces 252
Number of Solids 0
Number of Load Cases 6
Number of Load Combinations 48
Number of Result Combinations 0
Total Weight 2298.430 tons
Dimensions (Metric) 55.000 x 52.200 x 14.000 m
Dimensions (Imperial) 180.45 x 171.26 x 45.93 feet

You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
