How can I retrospectively reduce the determined provided longitudinal reinforcement in RF‑CONCRETE Columns?

FAQ|005005

Question:
How can I retrospectively reduce the determined provided longitudinal reinforcement in RF‑CONCRETE Columns?

Answer:
A result of the column design with RF‑CONCRETE Columns is the provided reinforcement. This is displayed in Table 4.1 and illustrated in the graphics below and in the table on the right.
You can use the "Edit Reinforcement" button to change the provided reinforcement, if necessary. (Image 01) Click the button to open the "Edit Longitudinal Reinforcement" dialog box (Image 02). It includes the table for "Position of Reinforcement Bars". Here, you can delete rows by selecting the row that contains the member to be removed, then clicking the button below.
Subsequently, it is necessary to recalculate the design for the modified reinforcement layout.

;
