Online Manual RFEM | Surfaces
Question: Is it possible to transfer properties, such as the cross-section, or the surface thickness and material of a surface of an existing element to a new element?
Answer: When creating a new element (a member, a surface, a solid), there is a corresponding function at the bottom of the dialog box that allows you to import the properties of another element (see Image 01).
After activating the function, click the element from which you want to transfer the properties. In addition to the geometry and the material, other settings, such as eccentricities or stiffness modifications, will be transferred as well.
Model Used in
Concrete Building
| Number of Nodes | 71 |
| Number of Lines | 77 |
| Number of Members | 2 |
| Number of Surfaces | 11 |
| Number of Solids | 0 |
| Number of Load Cases | 4 |
| Number of Load Combinations | 41 |
| Number of Result Combinations | 4 |
| Total Weight | 67.151 tons |
| Dimensions (Metric) | 5,000 x 5,500 x 5,000 m |
| Dimensions (Imperial) | 16.4 x 18.04 x 16.4 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
