Steel lattice girder
Submodels
Model Used in
Steel Lattice Girder
No Download Possible
Customer Project / View Only
Number of Nodes | 97 |
Number of Lines | 126 |
Number of Members | 30 |
Number of Surfaces | 54 |
Number of Load Cases | 2 |
Number of Load Combinations | 1 |
Total Weight | 2.188 tons |
Dimensions (Metric) | 16.100 x 0.344 x 1.772 m |
Dimensions (Imperial) | 52.82 x 1.13 x 5.81 feet |
Program Version | 5.01.00 |
