This article describes the elements with a cross-section subjected to a bending moment, a shear force, and an axial compressive or tensile force at the same time. However, the loading due to shear force is not included in our example.
Model Used in
Column Subjected to Combined Bending
| Number of Nodes | 2 |
| Number of Lines | 1 |
| Number of Members | 1 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 2 |
| Number of Load Combinations | 8 |
| Number of Result Combinations | 4 |
| Total Weight | 1.980 tons |
| Dimensions (Metric) | 0.000 x 6.000 x 0.000 m |
| Dimensions (Imperial) | 0 x 19.69 x 0 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
