The model appears to be a three-dimensional truss structure, demonstrating a blend of modern architectural design and engineering principles. The overall form is characterized by its smooth, undulating curves and the uniformity of the triangular grid, which provides both aesthetic appeal and structural stability.
Aluminium Grid Shell
| Number of Nodes | 104 |
| Number of Lines | 271 |
| Number of Members | 271 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 4 |
| Number of Result Combinations | 0 |
| Total Weight | 2.650 tons |
| Dimensions (Metric) | 8.000 x 6.062 x 17.000 m |
| Dimensions (Imperial) | 26.25 x 19.89 x 55.77 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
