Graduation Thesis 000471 | Lateral Torsional Buckling Under Influence of Axial Tension
Graduation Thesis 000471 | Lateral Torsional Buckling Under Influence of Axial Tension
Number of Nodes | 19 |
Number of Lines | 34 |
Number of Members | 0 |
Number of Surfaces | 16 |
Number of Solids | 0 |
Number of Load Cases | 12 |
Number of Load Combinations | 1 |
Number of Result Combinations | 0 |
Total Weight | 0.647 tons |
Dimensions (Metric) | 5.000 x 0.581 x 0.220 m |
Dimensions (Imperial) | 16.4 x 1.91 x 0.72 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
