Rechargeable Ferry
Number of Nodes | 7403 |
Number of Lines | 12180 |
Number of Members | 172 |
Number of Surfaces | 6842 |
Number of Solids | 1128 |
Number of Load Cases | 1 |
Dimensions (Metric) | 7.760 x 6.475 x 4.016 m |
Dimensions (Imperial) | 25.46 x 21.24 x 13.18 feet |
Program Version | 5.20.01 |
