Solid model of a steel axle box
Model Used in
Axle Support
| Number of Nodes | 196 |
| Number of Lines | 304 |
| Number of Members | 0 |
| Number of Surfaces | 136 |
| Number of Solids | 11 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 1 |
| Number of Result Combinations | 0 |
| Total Weight | 0.005 tons |
| Dimensions (Metric) | 0,581 x 0,361 x 0,160 m |
| Dimensions (Imperial) | 1.91 x 1.18 x 0.52 feet |
