Model of Quai M Concert Hall
No Download Possible
Customer Project / View Only
Number of Nodes | 1920 |
Number of Lines | 3355 |
Number of Members | 2269 |
Number of Surfaces | 130 |
Number of Solids | 0 |
Number of Load Cases | 11 |
Number of Load Combinations | 213 |
Number of Result Combinations | 6 |
Total Weight | 2892.589 tons |
Dimensions (Metric) | 42,949 x 15,100 x 36,289 m |
Dimensions (Imperial) | 140.91 x 49.54 x 119.06 feet |
