Steel Supporting Structure of Lift Station
No Download Possible
Customer Project / View Only
Number of Nodes | 537 |
Number of Lines | 810 |
Number of Members | 806 |
Number of Surfaces | 1 |
Number of Load Cases | 13 |
Number of Load Combinations | 464 |
Number of Result Combinations | 3 |
Total Weight | 87.556 tons |
Dimensions (Metric) | 42.826 x 27.580 x 9.403 m |
Dimensions (Imperial) | 140.51 x 90.49 x 30.85 feet |
Program Version | 5.27.01 |
