This model was used to demonstrate the usage of a garage door and properties of the member type "Spring".
Model Used in
Garage Door
Number of Nodes | 24 |
Number of Members | 31 |
Number of Load Cases | 1 |
Total Weight | 0.029 tons |
Dimensions (Metric) | 3.000 x 2.333 x 3.000 m |
Dimensions (Imperial) | 9.84 x 7.65 x 9.84 feet |
Program Version | 8.26.00 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
!["Spring" Member Type](/en/webimage/010409/3011652/01-en.png?mw=512&hash=65e98cfe859ce35a3e3e9da47a0ef9335401520e)
The RFEM5 and RSTAB8 programs offer a "Spring" option when defining a member under the member types.
![Saving and Importing Diagrams for Member Hinges](/en/webimage/010427/2984202/01-EN.png?mw=512&hash=17127434c06258f349409b3e8f047f6d0e8c4ea7)
In RFEM 5 and RSTAB 8, it is possible to assign nonlinearities to member hinges. In addition to the nonlinearities "Fixed if" and "Partial activity", you can select "Diagram". If you select the "Diagram" option, you have to specify the according settings for the activity of the member hinge. For the individual definition points, it is necessary to specify the abscissa and ordinate values (deformations or rotations and the according internal forces) that define the hinge.
