Parameterized FE Model for Design of Rigid End Plate Joints
No Download Possible
Customer Project / View Only
| Number of Nodes | 115 |
| Number of Lines | 195 |
| Number of Members | 70 |
| Number of Surfaces | 37 |
| Number of Solids | 1 |
| Number of Load Cases | 1 |
| Dimensions (Metric) | 2.010 x 0.200 x 0.220 m |
| Dimensions (Imperial) | 6.59 x 0.66 x 0.72 feet |
| Program Version | 5.01.00 |
