Modeling Cantilever as Member

Why is it suggested to model a cantilever using surface elements instead of a member element when studying buckling?


Answer:

Modeling a cantilever using surface elements provides a more accurate representation of local buckling behavior. Modeling it as a member may give a reasonable displacement result, but the critical load factor and buckling modes might not be realistic, especially when considering local buckling.

For more information, see our KB article on this topic:
