Parameterization of geometry of an industrial building with a rail girder, a curved roof modelled with steel bars and foundations consisting of isolated footings. Includes parametric loads and load combinations.
Model created by the technical team of Dlubal Latam. The model is also available as a parameterized block at the Dlubal Latam site.
Industrial Hall with Arc Roof
Block parameters editable dynamically | |
Number of Nodes | 260 |
Number of Lines | 320 |
Number of Members | 281 |
Number of Surfaces | 8 |
Number of Solids | 0 |
Number of Load Cases | 4 |
Number of Load Combinations | 10 |
Number of Result Combinations | 2 |
Total Weight | 54.722 tons |
Dimensions (Metric) | 21,750 x 11,700 x 19,750 m |
Dimensions (Imperial) | 71.36 x 38.39 x 64.8 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
