Plate Funnel made out of Q235 Steel with Square Inlet and Circular Outlet Stiffened by Angled Steel
Plate Funnel
| Number of Nodes | 96 |
| Number of Lines | 184 |
| Number of Members | 88 |
| Number of Surfaces | 36 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 5 |
| Number of Result Combinations | 0 |
| Total Weight | 4.657 tons |
| Dimensions (Metric) | 6.000 x 6.000 x 6.000 m |
| Dimensions (Imperial) | 19.69 x 19.69 x 19.69 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
