A video showing the different results calculated for LTB between an Eigenvalue analysis and Chapter F from the AISC.
KB 001679 | AISC Chapter F Lateral Torsional Buckling Versus Eigenvalue Calculation Methods Compared
Links
Do you have any questions?
![Steel Beam](/en/webimage/013895/2796237/2020-11-04_16-36-41.png?mw=512&hash=4639c92dc4bb2b8364042a2f706fc23743a50b1e)
Utilizing the RF-STEEL AISC add-on module, steel member design is possible according to the AISC 360-16 standard. The following article will compare the results between calculating lateral torsional buckling according to Chapter F and Eigenvalue Analysis.
![Warping Restraint via End Plate](/en/webimage/010484/2978100/1_warping_restraint_from_end_plate.png?mw=512&hash=b43e17cbb11faa3b51820d5bc88f6c5f2d58db81)
In the case of open cross-sections, the torsional load is removed mainly via secondary torsion, since the St. Venant torsional stiffness is low compared to the warping stiffness. Therefore, warping stiffeners in the cross-section are particularly interesting for the lateral-torsional buckling analysis, as they can significantly reduce the rotation. For this, end plates or welded stiffeners and sections are suitable.
![Entering Intermediate Lateral Restraint in Center of Member 1](/en/webimage/010537/2968407/1_Intermediate_lateral_restraint_in_the_middle_of_beam_1.png?mw=512&hash=b59e15e6f9f5b251a280addda3968092369a2f14)
The support conditions of a beam subjected to bending are essential for its resistance to lateral-torsional buckling. If, for example, a single-span beam is held laterally in the middle of the span, the deflection of the compressed flange can be prevented, and a two-wave eigenmode can be enforced. The critical lateral-torsional buckling moment is increased significantly by this additional measure. In the add-on modules for member design, different types of lateral supports on a member can be defined using the "Intermediate supports" input window.
