Eurocode 2 | Concrete Structures According to DIN EN 1992-1-1
2021-07-29
8:30 AM - 12:30 PM CEST
English
Price
250.00 EUR zzgl. MwSt.
Online training on reinforced concrete design according to DIN EN 1992-1-1
In this training, the verification of reinforced concrete structures according to the DIN EN 1992-1-1 standard is explained using the structural analysis software RFEM and the relevant add-on modules.
The add-on modules for concrete design according to EC 2 will be explained using relevant examples. The ultimate limit state (ULS), serviceability limit state (ULS), stability analysis and punching shear design will be covered during the training session.
Time Schedule
Basics of the design in RF-CONCRETE Members
Design specifications for member structures
Evaluation of results
Basics of design in RF-CONCRETE Surfaces
Design specifications for surface structures
Evaluation of results
Punching shear checks with RF-PUNCH Pro
Punching shear design and specifications
Evaluation of results
Additional Information
A reliable internet connection is required to participate. Basic user knowledge in RSTAB or RFEM is also required. The online training is carried out in RFEM and the associated add-on modules.
During the training, each participant can ask questions via chat at any time.
Each participant will receive the following after the event:
Participation certificate
Training presentation (PDF)
RFEM model examples
Training video recording
This information will allow the participant to independently revisit the training step-by-step for further review.
In order to take part in the online training, the participant will automatically receive the login information after the event registration.
Please register with your personal (company) email address. Certificate is issued for the name which is linked to the registered email address. Participation links is sent to this address, as well.
Dipl.-Ing. (FH) Paul Kieloch
Product Engineering & Customer Support
Mr. Kieloch provides technical support to our customers and is responsible for development in the area of reinforced concrete structures.
