The model represents a connection of a steel hall structure,
two stiffening elements of the wall bracing as well as two stiffening elements of the roof bracing are connected to the longitudinal wall columns, and furthermore, the truss frame is rigidly connected to the column; the upper chord of the truss is also rigidly connected to the lower chord of the truss.
Joint Node of Longitudinal Wall Column
| Number of Nodes | 15 |
| Number of Lines | 9 |
| Number of Members | 9 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 1 |
| Number of Result Combinations | 0 |
| Total Weight | 1.072 tons |
| Dimensions (Metric) | 6.500 x 5.000 x 10.000 m |
| Dimensions (Imperial) | 21.33 x 16.4 x 32.81 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
