Graduation Thesis 000474 | Comparison of Geometrical Nonlinear Analysis and Second-Order Theory for Steel Members in Torsion
Graduation Thesis 000474 | Comparison of GNA and SOT for Steel Members in Torsion
Number of Nodes | 76 |
Number of Lines | 38 |
Number of Members | 38 |
Number of Load Cases | 1 |
Total Weight | 13.943 tons |
Dimensions (Metric) | 4.326 x 37.653 x 0.653 m |
Dimensions (Imperial) | 14.19 x 123.53 x 2.14 feet |
Program Version | 5.32.02 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
