The model focuses on foundation slabs where the dynamic load wizard “Import Support Reactions” is used. The precise transfer of nodal and line loads allows for optimal load distribution. FAQ 005401 underlines the practical application of this feature. Users are provided with a reliable method to efficiently simulate support reactions.
Model Used in
Overall
This page has 0 user ratings.
| 5 star | ||
| 4 star | ||
| 3 star | ||
| 2 star | ||
| 1 star |
Foundation Plate with Load Transfer Wizard
| Number of Nodes | 12 |
| Number of Lines | 8 |
| Number of Members | 0 |
| Number of Surfaces | 1 |
| Number of Solids | 0 |
| Number of Load Cases | 3 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 52,500 t |
| Dimensions (Metric) | 10,000 x 0,000 x 7,000 m |
| Dimensions (Imperial) | 32.81 x 0 x 22.97 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
