This is a model of a church including loads and design modules of timber and concrete.
Church Made of Timber and Concrete Members
Number of Nodes | 352 |
Number of Lines | 357 |
Number of Members | 357 |
Number of Load Cases | 7 |
Number of Load Combinations | 53 |
Number of Result Combinations | 4 |
Total Weight | 95.270 tons |
Dimensions (Metric) | 10.485 x 17.159 x 13.858 m |
Dimensions (Imperial) | 34.4 x 56.3 x 45.47 feet |
Program Version | 5.25.01 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
