A kindergarten, designed according to Building Information Modeling (BIM), is currently under construction in the Tyrolean municipality of Schwoich.
The digital 3D model accompanies the construction project from design to completion.
AGA-Bau-Planungs GmbH
www.agabau.at
Top: Physical Revit model, middle: Analytical Revit model, bottom: RFEM model (© AGA-Bau)
The digital 3D model accompanies the construction project from design to completion.
AGA-Bau-Planungs GmbH
www.agabau.at
Top: Physical Revit model, middle: Analytical Revit model, bottom: RFEM model (© AGA-Bau)
Timber Frame Structure
No Download Possible
Customer Project / View Only
| Number of Nodes | 416 |
| Number of Lines | 585 |
| Number of Members | 490 |
| Number of Surfaces | 3 |
| Number of Load Cases | 29 |
| Number of Load Combinations | 3 |
| Total Weight | 84.699 tons |
| Dimensions (Metric) | 38.183 x 31.995 x 9.663 m |
| Dimensions (Imperial) | 125.27 x 104.97 x 31.7 feet |
| Program Version | 5.16.01 |
