May 2015 was the official opening of the art project "Solhjul" (in English: Sun Wheel), designed by artist Bo Karberg. The approx. 39-foot‑high wheel is located on the center island of a traffic circle in Give, Denmark. It is now the new symbol of the town.
Schmidt Nielsen ApS
Ingenieurbüro für Baustatik F.R.I.
Odense, Denmark
www.schmidtnielsen.dk
3D model (© Schmidt Nielsen)
Schmidt Nielsen ApS
Ingenieurbüro für Baustatik F.R.I.
Odense, Denmark
www.schmidtnielsen.dk
3D model (© Schmidt Nielsen)
Art Project
No Download Possible
Customer Project / View Only
| Number of Nodes | 40 |
| Number of Lines | 21 |
| Number of Members | 1 |
| Number of Surfaces | 20 |
| Number of Solids | 5 |
| Number of Load Cases | 1 |
| Total Weight | 0.000 tons |
| Dimensions (Metric) | 0.076 x 0.073 x 0.076 m |
| Dimensions (Imperial) | 0.25 x 0.24 x 0.25 feet |
| Program Version | 5.04.00 |
