You can move and copy objects directly in the display window in order to work more efficiently. However, if you want to deactivate this function, you can use the shortcut menu. For this, right-click in the view window and select the "Deactivate Drag & Drop" option in the list.
Activating and Deactivating "Drag and Drop"
How can I activate or deactivate the "Drag and Drop" function?
