This water slide was completely modeled in RFEM using arcs, splines, NURBS, and quadrangles, and shows how you can easily model complex structures in RFEM.
Water Slide
| Number of Nodes | 175 |
| Number of Lines | 288 |
| Number of Members | 141 |
| Number of Surfaces | 71 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 1 |
| Number of Result Combinations | 0 |
| Total Weight | 42.630 tons |
| Dimensions (Metric) | 9.065 x 13.800 x 9.039 m |
| Dimensions (Imperial) | 29.74 x 45.28 x 29.66 feet |
