The model presents a space truss structure characterized by a hyperbolic paraboloid form. This design combines elements of a space truss and a hyperbolic paraboloid to achieve a lightweight yet robust system. Such structures are known for their aesthetic appeal and structural efficiency, commonly used in modern architectural applications. This model helps in visualizing and analyzing complex geometric shapes relevant to architects and engineers for innovative structure designs.
Overall
This page has 0 user ratings.
| 5 star | ||
| 4 star | ||
| 3 star | ||
| 2 star | ||
| 1 star |
Hyperbolic Paraboloid Space Truss
| Block parameters editable dynamically | |
| Number of Nodes | 162 |
| Number of Lines | 560 |
| Number of Members | 560 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 83.258 tons |
| Dimensions (Metric) | 44,000 x 21,666 x 30,000 m |
| Dimensions (Imperial) | 144.36 x 71.08 x 98.43 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
