Building of "Kranhaus" (crane house) in Cologne, Germany
Kranhaus
No Download Possible
Customer Project / View Only
Number of Nodes | 55 |
Number of Lines | 93 |
Number of Surfaces | 36 |
Number of Load Cases | 2 |
Total Weight | 7482.580 tons |
Dimensions (Metric) | 81.677 x 53.604 x 68.040 m |
Dimensions (Imperial) | 267.97 x 175.87 x 223.23 feet |
Program Version | 5.23.00 |
