In SHAPE-THIN, you can import cross-section geometries that are available as contour or centroid layouts in DXF format and use them as a basis for modeling.
KB 001607 | Cross-Section Modeling Based on DXF Files
![Dialog Box "Insert DXF Template"](/en/webimage/008752/1444692/01-en.png?mw=512&hash=65e98cfe859ce35a3e3e9da47a0ef9335401520e)
![Allplan Model](/en/webimage/046832/3673916/1.png?mw=512&hash=9d7f6c198b6d4ae6ee8f2fa8bca75f85579e14c9)
![WebService & API C# - Cover Image](/en/webimage/039826/3501825/Featureimage_english.png?mw=512&hash=155589b198d693fea6bf8f7eba4440f2e17d1638)
![KB 001769 | Practical Applications Using Python and RFEM 6 | 2D Truss Generator](/en/webimage/034773/3394268/2022-10-11_14-45-11.jpg?mw=512&hash=c51c9c6989137e5f04312884c6507042712f3740)
![Feature 002796 | Console with Python Option](/en/webimage/050930/3925245/1.png?mw=512&hash=9d7f6c198b6d4ae6ee8f2fa8bca75f85579e14c9)
In addition to JavaScript, the Python high-level functions are also available in the console. Using the Python option, the console also provides you with the Python HLF functions known from the WebService function catalog for further use in the object properties dialog box for in-app scripting.
![Feature 002693 | Export to SVG Format (Vector Graphic)](/en/webimage/044991/3671679/2023-12-21-10-38-38.png?mw=512&hash=fb92be9ab90efcf7c481c72396ff5f26f87ac00c)
In RFEM 6 and RSTAB 9, you can export line graphics to the SVG format (vector graphics).
SVG stands for Scalable Vector Graphics and is an XML-based file format for displaying two-dimensional vector graphics. These vector graphics can be scaled without loss. It is possible to edit the SVG files using text editors, embed them on websites, and open them in the usual browsers.
![Data Transfer from MS Excel to RFEM 6](/en/webimage/000052/517816/1-en.png?mw=512&hash=2f0018b00b526e3852def3f63ee3e343e51b99d4)
You can import table values from a prepared Excel table into RFEM 6 / RSTAB 9 with just a few clicks – either individually or all at once. For the import, you need to install a plug-in in Microsoft Excel according to this FAQ: Is the import from Microsoft Excel still available in RFEM 6? .
![Export Specifications for MS Excel](/en/webimage/000053/3405331/000053_EN.png?mw=512&hash=eca3216be3c2bccaad3d3fced7fd69927f1c2a35)
Did you know? You can export all RFEM/RSTAB tables with the results individually or all at once directly into an Excel table or as a CSV file. There are several options available to you:
- With table headers
- Selected objects only
- Filled rows only
- Only filled tables
- Export data as plain text
This way, the program allows you to control and clearly manage the exported data. You can export the stored formulas directly in the table or as a separate table, as in the case of the used parameters.
