This model was created using the Multilayer Surfaces and the Timber Design add-on.
The ceilings were created from seven orthotropic layers of softwood, each glued at an angle of 90° to each other.
Adjustments have been made in the material properties to change the modulus of elasticity in the y-direction, and new structural modifications have been created.
Alpine Hotel Made of Glulam
| Number of Nodes | 164 |
| Number of Lines | 259 |
| Number of Members | 121 |
| Number of Surfaces | 80 |
| Number of Solids | 0 |
| Number of Load Cases | 3 |
| Number of Load Combinations | 16 |
| Number of Result Combinations | 0 |
| Total Weight | 239.606 tons |
| Dimensions (Metric) | 15.000 x 9.000 x 14.600 m |
| Dimensions (Imperial) | 49.21 x 29.53 x 47.9 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
